The Deluxe Universal Wind Triangle & T/S/D 4-colour computer calculates flight planning and en route navigation requirements. The unit includes wind slide speeds of 40 to 270 kts or miles, colour-coded conversion scales, slide lock, flush compass ring, and write-in TC to CH boxes.The slide has Nautical and Statute rulers for Sectional and WAC charts, typical east/west magnetic variation diagrams, wind triangle definitions, true heading and true course solutions, and a headwind and crosswind component grid.
Instructions to solve for ground speed, WCA, and headings are printed on the computer and make learning faster and easier. The Time/Speed/Distance computer provides all major navigation computations.The flight planning side of the wind triangle slide shows formulae for true course to compass headings as well as illustrated examples of east/west magnetic variation. Also displayed are definitions relevant to wind triangle problems and diagrams of true heading and true course solutions.The headwind and crosswind component grid depicts the relative wind angle in a multi-color graphic for accurate and easy interpretation. Nautical and Statute scales for Sectional and WAC Charts are printed on the sides of the slide.
Custom case. Lifetime, anodized aluminum. Dimension: 4 7/8" x 9 5/8". Complete Instruction Manual includes BONUS Section on Dead Reckoning and Wind Effect Theory Calculations. Miles and Gallons Scale (Distance) Off-course & Drift Corrections Minutes & Hours Scale (Time) Mach Number Index Window Slide-Rule Mathematics Wind Component Grid Colour-Coded Conversion Scales Microset Alignment Wind Slide Lock Flush T/S/D Dial Altitude Correction Fuel Consumption Density Altitude Factors Conversions Minutes to Seconds True Airspeed True Altitude Temperature Kilometers Statute to Nautical to Statute Miles APR makes a number of different E6-B flight computers and the differences are sometimes hard to figure out.
